Defining system resources
ADM003GVAE1005 61
Importing/exporting string information
User-defined strings can be imported or exported using comma-delimited text files
(*.csv). The header and strings have to be imported/exported separately.
Importing strings
Coded variables
Coded Variables are used for input and output processing as well as alarm
processing. Coded Variables can be used to build alarms and to display process
or equipment status on graphics and reports.
FuelsManager allocates the first 512 Coded Variables. These standard Coded
Variables are used for FuelsManager processes and cannot be modified. The
predefined variables include most common process control states including
equipment status, alarm states, months of the year, and equipment commands.
If the list is not sufficient, the user has the ability to create new Coded Variables.
Once created, the Coded Variables are available for assignment in the database.
EDIT Allows any of text of the current string selection in the Edit
String text box to be modified.
REPLACE Replace the current string selection with the text in the
Edit String text box.
INSERT Insert a new blank string above the selected string.
CLEAR Clear the current string selection of any text.
DELETE Delete the current string selection from the list
completely.
Step-by-Step
• In the Configuration dialog box, select the Strings command from the
Resources menu. From the Strings sub-menu select Add Type. The String
Configuration dialog box appears
• Select either Header or String option button. The Header options button
import header information (user-defined name and maximum length). The
String option button imports the string (the list of strings for the user-defined
type)
• Click Import
• The Import User String Header or the User String table appears
• Select the file to import and click Open
• The String Configuration dialog box displays the Header or String
information imported
String configuration dialog box
