FuelsManager Defense
96 Administrator Manual
Add Point to Database dialog box
DIALOG BOX
TITLE
The title of the dialog box displays the Current Database
System to which the point will be added
ACTIVE TAG
LEVELS
The Active Levels field displays the number of database tag
levels for the selected database
LEVEL 2, 1, 0 The Level 2, Level 1 and Level 1 fields allow the user to
enter the database tagname for the point to be created.
Levels 2 or 1 will default to the database level already
selected in the Database Edit dialog box (if any)
Note! The example dialog box shows a three level database, an alternate
dialog box exists for four level databases. For databases with less than three
levels the Level 2 or Level 1 fields will be disabled.
POINT TYPE The point type group allows the user to select the type of
point to be created. refer to the previous descriptions of the
different types points
