Creating and editing tank points
ADM003GVAE1005 129
Strap, Water and Hydro Definition Modes
FuelsManager can be configured to calculate gross volume by one of two different
methods:
• Combined product and water tables
• Separated product and water tables
These selections control how the product and water tables overlap and how
FuelsManager should interpret the volumes at the point where the two overlap.
For more details, see the Product & Water Strapping Tables section of the Tank
Calculations chapter.
Leak Detection
If your system has the Leak Detection feature installed, a Leak Detection tab
appears on the Edit Tank Point dialog box. For details on these configuration
parameters, please refer to the Leak Detection section of this manual.
OUTAGE The Outage option button measures the actual free space in
the tank displaying the Level measurement value from high
to low. When the Outage option is selected, the following
applies:
Alarm settings (In the Alarm tab) are recalculated to reflect
your Outage selection:
High-High - must be less than High and activates when the
tank level is equal to or less than the setpoint.
High - must be less than Low but greater than High-High
and activates when the tank level is equal to or less than the
setpoint.
Low - must be less than Low-Low but greater than High and
activates when the tank level is equal to or greater than the
setpoint.
Low-Low - must be greater than Low and activates when
tank level is equal to or greater than the setpoint.
Volume calculations - are based on the Strap table with the
exception of Water Volume and Bottom Volume for Outage.
These volumes are calculated as if the Strap table was an
Innage table
Edit Tank Data dialog box - Strap/Water Table tab
