FuelsManager Defense
128 Administrator Manual
DENSITY This field allows the user to edit the strapping table density.
This value is the density at which the strapping table was
created and is used in FuelsManager volume calculations
TEMPERATURE This field allows the user to edit the strapping table
temperature. This value is the temperature at which the
strapping table was created and is used in FuelsManager
volume calculations
ADD This button allows the user to add a new entry at the end of
the strapping table
DELETE This button removes the currently selected entry from the
strapping table
INSERT This button allows the user to add a new entry at the
currently selected position in the strapping table
EXPORT This button allows the user to export the tank strapping
table to a proprietary formatted text file. This allows the user
to edit the information offline using 3rd party tools like
Notepad
IMPORT This button allows the user to import a previously exported
tank strapping table
STRAP TABLE
TYPE
This group allows the user to configure the type of strapping
table to be used, either Innage or Outage. A tank may be
converted from Innage to Outage by simply changing the
selection in the Strap table Type. The system calculates the
new Outage Strap table based on the Innage table and
recalculates the new alarm setpoints. A tank may also be
converted from Outage to Innage by the same process
INNAGE The Innage option button is the default value for new tanks
and measures the actual fluid in the tank, displaying the
Level measurement values from low to high. When the
Innage option is selected, the following applies:
Alarm settings under the Alarm tab are recalculated to
reflect your Innage selection:
High-High - must be greater than High and activates when
the tank level is equal to or greater than the setpoint.
High - must be greater than Low but less than High-High
and activates when the tank level is equal to or greater than
the setpoint.
Low - must be greater than Low-Low but less than High and
activates when the tank level is equal to or less than the
setpoint.
Low-Low - must be less than Low and activates when the
tank level is equal to or less than the setpoint.
Volume calculations - are based on the Strap table
Edit Tank Data dialog box - Strap/Water Table tab
