Sealing the Point in 8130 RTU
ADM003GVAE1005 325
Enraf 873 Yes Module
Chan
CIU
Addr
ID
TOI
ScanCmd
LevelUnits
TempUnits
LevelDeadband
TempDeadband
External Module
Address
Channel for Communications
CIU Address
Tank Gauge ID
Type of Instrument
Scan Commands for Instrument
F=ft; M=Meters; m=millimeters
F=Fahrenheit; C=Celsius
Change of State (COS) Level Deadband.
Change of State (COS) Temp Deadband.
GSI Model 2000 No
ITT Barton 3500 No
L&J MCG1000 No
L&J MCG1500 No
L&J MCG2000 No
NMS53 Yes Module
Chan
CIU
Addr
ID
TOI
ScanCmd
LevelUnits
TempUnits
LevelDeadband
TempDeadband
External Module Address
Channel for Communications
Tank Gauge ID
Gauge / Scanning Mode
F=ft; M=Meters; m=millimeters
F=Fahrenheit; C=Celsius
G=g/ml; A=API; L=lbs/ft
3
Change of State (COS) Level Deadband
Change of State (COS) Temp Deadband
SAAB L/2 Radar Yes Module
Chan
ID
LevelUnits
LevelConvert
LevelDeadband
External Module Address
Channel for Communications
Tank Gauge ID
m=millimeters; s=sixteenths
Convert Level to standard
Change of State (COS) Level Deadband
Tank Side Monitor Yes Module
Chan
ID
BaudRate
ComParams
ModeLevel
Deadband
Temp
Deadband
External Module Address
Channel for Communications
Tank Gauge ID
Baud Rate Data bits & Parity
Operating Mode
Change of State (COS) Level Deadband.
Change of State (COS) Temp Deadband
Point Type WMSeal Parameters Sealed Parameter Description
