Tank Alarms Data
ADM003GVAE1005 355
LEVEL HIHI ETA - HIGH HIGH LEVEL ETA
This variable is the estimated time to arrive at the High-High level alarm setpoint based on the current flow rate.
The alarm is activated when the time remaining before reaching the High-High level setpoint is less than the
advisory limit defined by the Trans. Adv. Setpoint (see Product Transfer Data section)
LEVEL HIGH ETA - HIGH LEVEL ETA
This variable is the estimated time to arrive at the High level alarm setpoint based on the current flow rate. The
alarm is activated when the time remaining before reaching the High level setpoint is less than the advisory limit
defined by the Trans. Adv. Setpoint (see Product Transfer Data section)
LEVEL LOW ETA - LOW LEVEL ETA
This variable is the estimated time to arrive at the Low level alarm setpoint based on the current flow rate. The
alarm is activated when the time remaining before reaching the Low level setpoint is less than the advisory limit
defined by the Trans. Adv. Setpoint (see Product Transfer Data section)
LEVEL LOLO ETA - LOW LOW LEVEL ETA
This variable is the estimated time to arrive at the Low-Low level alarm setpoint based on the current flow rate.
The alarm is activated when the time remaining before reaching the Low-Low level setpoint is less than the
advisory limit defined by the Trans. Adv. Setpoint (see Product Transfer Data section)
TEMPERATURE ALARM - COMPOSITE TEMP. ALARM STATUS
This variable is a composite value that displays a coded variable representing the highest priority temperature
alarms for the tank. Possible values are Normal, High-High, High, Low, Low-Low. This alarm is calculated by
FuelsManager based on the current temperature and the alarms limits configured for the tank
TEMP HIHI LIMIT - CURRENT HI-HI TEMP LIMIT
This variable is the limit for a High-High temperature alarm. If the tank temperature exceeds the HiHi Alarm
value, then a High-High alarm is activated. This variable is entered when configuring the tank point, but can be
modified from Operate by a user with sufficient privileges
TEMP HIGH LIMIT - CURRENT HIGH TEMP LIMIT
This variable is the limit for a High temperature alarm. If the tank temperature exceeds the High Alarm value,
then a High alarm is activated. This variable is entered when configuring the tank point, but can be modified from
Operate by a user with sufficient privileges
TEMP LOW LIMIT - CURRENT LOW TEMP LIMIT
This variable is the limit for a Low temperature alarm. If the tank temperature falls below the Low Alarm value,
then a Low alarm is activated. This variable is entered when configuring the tank point, but can be modified from
Operate by a user with sufficient privileges
TEMP LOLO LIMIT - CURRENT LO-LO TEMP LIMIT
This variable is the limit for a Low-Low temperature alarm. If the tank temperature falls below the LoLo Alarm
value, then a Low-Low alarm is activated. This variable is entered when configuring the tank point, but can be
modified from Operate by a user with sufficient privileges
