Local location information management using EDM
Use the
information in this section to view and add local location information for remote network
devices connected to a switch or stack.
Viewing device location information using EDM
Use this procedure to display local location information for remote network devices connected
to a switch or stack.
Procedure steps
1. From the navigation tree, double-click Edit.
2. In the Edit tree, double-click Diagnostics.
3. In the Diagnostic tree, double-click 802.1AB.
4. In the 802.1AB tree, double-click Port MED.
5. On the work area, click the Local Location tab.
Variable definitions
Use the data in the following table to help you understand the remote device local location
information display.
Field Description
PortNum Identifies the port number of the local system
to which the remote device is connected.
LocationSubtype Indicates the location subtype advertised by
the remote device.
• unknown
•
coordinateBased—location information is
based on geographical coordinates of the
remote device
• civicAddress—location information is
based on the civic address of the remote
device
• elin—location information is based on the
Emergency Location Information Number
(ELIN) of the remote device
LocationInfo Displays local location information
advertised by the remote device. The
information displayed in this cell is directly
associated with the location subtype value.
LLDP Port MED configuration using EDM
Configuration — System April 2011 321
