RELAY CONFIGURATION F
OR CBX100/800
PRODUCT REFERENCE GUIDE
81
Schematics for Isolat
ed and
Non-Isolat
ed relays are pr
ovided below
.
Outputs 1 and 2
Maximum V
oltage 30V
Collector Cur
rent (pulse) 130 mA Max.
Collector Cur
rent (continuous) 40 mA Max.
Saturation V
oltage (VCE) 1 V at 10 mA Max.
Max Pow
er Dissipation 90 mW at 50 degrees C
(Ambie
nt temperatur
e)
Unpow
ered Outputs
100
102
