ELECTRICAL INSTALLATION
70
AV7000 LINEAR CAMERA
Digital Output Configur
ation from CBX510
The CBX510 includes an OUTPUT
S block for wiring rela
ys as needed for e
xternal acces
-
sories.
Schematics f
or Isolated and Non-Isolat
ed digital outputs are pr
ovided below
.
Outputs 1 - 3
Maximum V
oltage 30 Vdc
Collector Cur
rent (pulse) 130 mA Max.
Collector Cur
rent (continuous) 40 mA Max.
Saturation V
oltage (VCE)
1 V at
10 mA Max.
Maximum Pow
er Dissipation 90 mW at 50°C (Ambient
te
mperatur
e)
89
91
