PRODUCT REFERENCE GUIDE
45
CHAPTER 3
ELECTRICAL INSTALLATION
PREPARING FOR ELECTRICAL INSTALLATION
Before mounting any components, please do the following:
• Read all instructions before beginning your installation.
• Observe all electrical safety requirements discussed in the Introduction to this
manual.
• Define and confirm the accuracy of your application’s requirements.
• Review all installation-specific drawings.
• Review and plan the power requirements for your application.
• Review and plan the communications requirements for your application.
ESD CAUTION: The AV7000 contain electronics that may be affected by
electrostatic discharge (Electrical Installation must be performed by Quali-
fied Service Technicians Only! Procedures may involve exposure to high-
voltage. A trained and authorized technician must perform these proce-
dures. Do not attempt to perform any electrical installation procedures
unless you are a trained technician.
WARNING: The content of this manual may be superseded by any cus-
tomer-specific documentation provided by Datalogic. Before proceeding
with any installation procedures, be sure to review ALL documentation,
especially content that contains details specific to your installation.
NOTE: Everything should be MECHANICALLY INSTALLED before performing
any ELECTRICAL INSTALLATION. See Chapter 2 for mechanical installation
details.
Most AV7000 applications are shipped with the CBX connection box and all
the necessary cabling required to electrically install the system. If your
system requires custom-length cables or other special wiring, documenta-
tion specific to these requirements has been provided in your shipment.
This special documentation supersedes any contradictory content in this
manual.
To reduce the possibility of damage to the unit, check all cabling between
the AV7000 camera and other devices for accuracy.
