MECHANICAL INSTALLATION
24
AV7000 LINEAR CAMERA
INSTALLATION SEQUENCE
To complete mechanical installation and setup, you must:
1. Review the details of your application’s requirements
2. Erect mounting structure or other supporting structures
3. Determine and mark the Mounting Bracket locations
4. Mount the fan assembly to the AV7000 Camera
5. Pre-Assemble the illuminator brackets
6. Mount the AI7000 Illuminator to its mounting brackets
7. Mount the brackets to the mounting structure.
8. Mount the AV7000 Camera to the Illuminator
9. Mount the brackets for the deflection mirror, if required.
10. Mount the deflection mirror to its brackets
11. Mount the height sensor (AS1, Light Curt
ain, RangeFinder, DM3610 Dimensioner,
or S85)
12. Mount the photoelectric sensor to the mounting structure (optional)
13. Mount the tachometer to the mounting structure
14. Mount the CBX connection box to the mounting structure
15. Complete electrical installation (See “Electrical Installation” on page 49.)
16. Align the AV7000 for proper operation
17. Align the height sensor for proper operation
18. Configure the AV7000 (See “E-Genius Basics” on page 92.)
19. Calibrate the AV7000 (See “Setup and Calibration” on page 348. )
20. Check AV7000 operations.
NOTE: Everything should be MECHANI
CALLY INSTALLED before performing
any ELECTRICAL INSTALLATION. See Chapter 3, Electrical Installation for
electrical installation details.
