INTRODUCTION
18
AV7000 LINEAR CAMERA
Encoder (T
achometer)
The encoder/tachomet
er delivers a continuous pulse
to the sys
tem, which provides
feedback on c
onveyor speed and tr
ansmit point, and can be used to help track the pack
-
age position along the length of the con
veyor
.
Encoder (T
achometer)
OEK-2 OPTICAL ENCODER (CAB 10m+SPRING)
93ACC1770
OEK-3 OPTICAL ENCODER HI RES,6M CBL+SPRI
93ACC0056
OEK-3 ENCODER HI RES M139,6M CBL +SPRI (ST
ART/STOP ANTI ROLL
-
BACK)
93ACC0104
37
39
