PRODUCT REFERENCE GUIDE
165
Logical Combination Rule = 1^2&5^3^4&8^6^7 (3 groups)
Results Without Priority Filter:
Group 1 - read either code 1 or 2 = Good Read; read both code 1 and 2 = Multiple Read
Group 2 - read either code 5 or 3 or 4 = Good Read; read any combination = Multiple Read
Group 3 - read either code 8 or 6 or 7 = Good Read; read any combination = Multiple Read
Results With Priority Filter:
Filter Enabled on Groups = 1,3
Filter Type =Custom
Custom Filter Pattern String = 1^2&8^6|7 (2 groups)
Group 1 - read code 1 = Good Read independent from reading code 2
Group 2 - read either code 5 or 3 or 4 = Good Read; read any combination = Multiple Read
Group 3 - read code 8 = Good Read independent from reading code 6 or 7; no read on code 8
and read either code 6 or 7 = Good Read; no read on code 8 and read both code 6 and 7 =
Multiple Read
Advanced Filter String
Enter the character string (see above).
2. When you have finished making changes, click Update to save or click Reset to
revert to the previously saved values. 0)
Logical Combination Rules
The following are examples of rules used with Logical Combination selection in Barcode
Configuration. For all the following examples the No Read Message parameter is set to
Global No Read Message.
Example 1
Code label setting#1 = Code 128
Logical Combination Rule = 1&1
Defines 2 groups, each of them expecting a
Code 128 label.
Decoded Code Symbology
Output Message
First Label
#1
Second Label
#1
--- --- <Header><Global No Read Message><Terminator>
X --- <Header><Global No Read Message><Terminator>
--- X <Header><Global No Read Message><Terminator>
X X
<Header><Code 128 data><Data Packet Separator><Code
12
8 data><Terminator>
NOTE: In all of the examples, Partial must be set to “treat as no read.
