ELECTRICAL INSTALLATION GUIDELINES
It is important that you follow these general precautions when installing, setting up,
operating, maintaining, troubleshooting or replacing any Datalogic products, parts or
related equipment.
As you plan and install your barcode reader(s), be sure to keep the following guidelines
in mind:
• Determine the camera is in the proper location as outlined in Chapter 2.
• Leave adequate clearances (approximately 300mm [12 in]) for wiring.
• Route wires carefully to reduce or minimize electrical noise.
• When extraneous power and communication wiring must cross, make their inter-
section perpendicular. Avoid running power and data wiring parallel to each other.
If possibl
e, maintain one of the following separations between the power and
data wiring:
• 300 mm [12 in] gap
• use steel conduit and 25 mm [1 in] gap
• 6.5 mm [0.25 in] of aluminum.
WARNING: When planning your installation wiring, remember all power
connections must be quick-disconnect. For PERMANENTLY CONNECTED
EQUIPMENT a readily accessible disconnect device must be incorporated in
the building installation wiring. For PLUGGABLE EQUIPMENT the socket-
outlet must be installed near the equipment and must be easily accessible
To assure no ESD damage will occur, be sure to observe the precautions
outlined in the Introduction to this manual.
Ground the mounting structure to safety ground (protective earth ground
(PE)).
