ELECTRICAL INSTALLATION
62 AV7000 LINEAR CAMERA
Selecting the Correct CBX Connection Box for Your Application
As shown in section , typical applications require a single CBX connection box to connect
the trigger and encoder inputs to the master camera. The camera sources power to
these devices. Other possible CBX connections are for digital outputs or a serial host.
•
CBX100 - used for slave cameras (and as an alternative for master cameras). It
provides general access to digital input/output signals.
•
CBX510 - used for standalone or master cameras. It provides general access to
digital input/output signals. It doesn't require special jumpers to set operation or
power sourcing.
•
CBX800 - used for Fieldbus communication between standalone or master cam-
eras and a Host. Various Fieldbus modules can be installed in the CBX800. The
mas
ter camera communicates through its main serial interface to the CBX800
which must be programmed for the specific Fieldbus communication to the Host.
It also provides general access to digital input/output signals.
The table below indicates the available options for each recommended CBX Connection
Bo
x.
Device
Tach
Input
Trigger
Input
General
Pu
rpose
Input
General
Purpose
Output 1
General
Purpose
Output 2
Works
as a
Slave
Works as a
Master
CBX100 X X X X X
with
jump
er
CBX510 X X X X X X
CBX800 X X X X X X
with
jump
er
CBX100/CBX510/CBX800 INITIAL CONFIGURATION
Complete installation information on these connection boxes is available in the
CBX100,CBX510, and CBX800 Installation Manuals available at www.datalogic.com.
CBX510
Please verify that the CBX510 connection box is configured for the AV7000 application
as follows:
WARNING: Although multiple AV7000 cameras can have a CBX box, only
one of the CBX boxes in the system can have the Jumper to make it the
Master.
