22
AV7000 LINEAR CAMERA
CHAPTER 2
MECHANICAL INSTALLATION
PREPARING FOR MECHANICAL INSTALLATION
Before mounting any components, please do the following:
• Read all instructions before beginning your installation.
• Define and confirm the accuracy of your ap
plication’s requirements and structure
position, especially the height of the conveyor from the floor.
• Review all installation-specific drawings provided with your equipment.
• Review and plan the mechanical installation of all devices used in your application.
Be
sure to allow adequate clearance for maintenance.
• Review and plan the power requirements for your application.
• Check the contents of the shipping cartons against the packing list.
• Record all product serial numbers.
ESD CAUTION: AV7000 cameras contain electronics that may be affected by
electrostatic discharge (ESD). To prevent personal injury or damage to the
unit, please follow the safety precautions and warnings found in the Refer-
ences section at the beginning of this manual. Failure to follow these pre-
cautions may void your warranty.
NOTE: Application-specific drawings and documents provided by Datalogic
supersede any contradictory content in this manual.
NOTE: Refer to the Chapter 3 Electrical Installation and Reference Docu-
mentation for details on connecting your readers to other devices in the
system.
When installing several AV7000s, take care to position them so that no
laser beam or LED illumination enters the reading window of other barcode
reading devices in the system. This condition could occur more frequently
for side mounted applications. If these precautions are not followed, read
rate could be negatively affected. To resolve this problem, it is sufficient to
slightly change the inclination and/or position of one of the two devices
involved.
