SETTING UP THE DM3610 DIMENSIONER
PRODUCT REFERENCE GUIDE
369
15. To adjust the distance, press enter each time you make an adjustment.
16. Enter this displayed value in the Operating Mode > Far Distance Offset field.
17. Click Upda
te to save your changes.
SETTING UP THE DM3610 DIMENSIONER
DM3610 Dimensioners provide focus data for Datalogic cameras, including the AV7000,
NVS9000, and AV6010. See
“DM3610 Dimensioner” on page 362.
Refer to the
DM3610 Dimensioner Reference Manual (or Two-Head Dimensioner Ref-
erence Manual) for complete information on ins
tallation and calibration of the
DM3610. It is available for download from
www.datalogic.com.
Preparation
Before beginning the DM3610 focusing process, a few preliminary settings are required.
1. In the DM3610 e-Genius under Modify Settings, navigate to Serial | Main or Aux
depending on the port wired to the AV7000 (typically Main, consult your applica-
tion interconnect diagrams for details). The Serial |
Main window opens.
NOTE: For single Dimensioner applications,
the DM3610 must be running
software version 1.8.11 or greater. For multi-head applications, the
DM3610’s must be running 1.8.1 and the DC3000 must be version 1.3.60 or
greater.
The Dimensioner scan line must be installed at least 500 mm [20 in]
upstream from the nearest camera scan line.
The examples used in this guide use Imperial units i.e. inches. If the sys-
tem is configured for metric, the unit of measure will be in mm.
Remember to reset these parameters to the application specifications after
the calibration is complete.
NOTE: When working with a multi-head Dimensioning system, the focus
setup steps apply to the unit designated as the “Tach Master” by the
DC3000.
