REPLACING AN AV7000 CAMERA
PRODUCT REFERENCE GUIDE
427
Other Camera Checks
Confirm communication with host
• Serial (if applicable)
• Ethernet (if applicable)
• Confirm Protocol Index (if applicable)
Observe the System in Action
Confirm that all cameras are reading the barcode correctly and that the scan point is
c
ommunicating to the host.
REPLACING AN AV7000 CAMERA
Use the following procedures to replace an AV7000 Camera, either a stand-alone unit, a
Master in a tunnel/array, or a Slave unit in a tunnel/array.
1. Disconnect the power source from the camera.
2. Disconnect all the cables except for the fan cable from the camera.
3. Remove the camera from the illumination by unscrewing the four (4) mounting
bolts.
NOTE: You will need an AV7000 Controller Key.
NOTE: Observe precautions to prevent Electrostatic Discharge (ESD).
Use
an ESD grounding wrist strap and avoid direct contact with circuit boards,
which could be damaged by ESD.
