WHAT YOU WILL NEED
PRODUCT REFERENCE GUIDE
361
WHAT YOU WILL NEED
•
•
• Application Drawing (for structure, camera, mirror, sensor and focusing device
positioni
ng)
• Application Specifications
•Laptop PC
• Tape Measure
• Sync Ethernet Cable Adapter
• Installation Kit (Test Boxes) (included with AV7000)
• CH-3 Autofocus Test Chart (included with AV7000)
• Dynamic Focus Target (included with AV7000)
• Picket Fence/Step Ladder Test Chart
• RangerOScope (software): Download from e-Genius, Utilities
| Download Tools
window. Click RangeFinder Tools (Only when using RangeFinder for focusing)
• CodeWord Viewer: Download (Only when using RangeFinder for focusing)
• Inventory All Equipment and Structure Parts
See“AV7000 Timing and Distance Diagrams” on page 129.
FIRST-TIME STARTUP
On initial power-up, the AV7000 performs a series of self-diagnostic and LED tests.
When the STATUS LED turns a steady green the power-up sequence is complete, and
the camera is operational.
The AV7000 cameras are shipped from the factory with these defaults:
• Def
ault User ID: setup (case sensitive)
• De
fault Password: DLAset (case sensitive)
• Control Panel Buttons Enabled
• IP address - 192
.168.0.145 (setup/sync controller), 192.168.3.10 (Host), and
10.0.40.20 (Image)
UNDERSTANDING DATALOGIC FOCUSING OPTIONS
There are several Datalogic focusing options available for the AV7000. Each option
serves a different purpose in AV7000 systems. They can be used alone or in combination
with one another. Below is a list of the available options and an explanation of their pur-
pose. The following sections detail how to f
ocus each device when used in an AV7000
system. Also see
“AV7000 Timing and Distance Diagrams” on page 129.
S-60 Photocell
The standard S-60 Photoelectric sensor is used in AV7000 Camera Fixed Focus systems
to detect the presence of an item entering the scanning area. This device works best in
systems where packages are separated by an open space between the trailing edge of
one package and the leading edge of the next.
NOTE: Items listed below are not required for ev
ery focusing option.
