PRODUCT REFERENCE GUIDE
267
Device Settings | Camera #n | Ethernet
Use the Ethernet menu selections to set up communications through Ethernet. If neces-
sary, you can later make modifications to the device settings using the same menu
selections, includi
ng (click on the menu item to access that help window):
• “Ethernet | Host Port” on page 267
• “Ethernet | Image Port” on page 268
• “Ethernet | Advanced Routing” on page 268
Ethernet | Host Port
Use the Host Port window to set up network communications to the Host.
To edit the Host Port settings:
1. In the menu tree under Modify Settings, navigate to Modify Settings | Device
Settings | Camera N | Ethernet | Host Port.
The Host Port window opens.
2. Enter the appropriate information in the form as described below:
Enable DHCP
Select the check box to use addresses assigned by a DHCP server. When this option is not
selected, the static IP options are made available.
IP Address
Enter the device Internet Protocol (IP) network address in the field provided. Consult your
network administrator to obtain a new address. Available only in static IP mode (when DHCP is
not selected).
Subnet Mask
Enter the device subnet mask address in the field provided. Consult your network
administrator to obtain a new address. Available only in static IP mode (when DHCP is not
selected).
Gateway
Enter the device gateway address in the field provided. Consult your network administrator to
obtain a new address. Available only in static IP mode (when DHCP is not selected).
Auto DNS Enable
Select the check box to automatically assign a DNS address. When not selected, the DNS
Address field is revealed. Available only in static IP mode (when DHCP is not selected).
DNS Address
Enter the address of the Secondary Domain Name System (DNS) in the field provided.
3. When you have finished making changes, click Update to save or click Reset to
revert to the previously saved values.
