SCANNING STATION FRAME/MOUNTING STRUCTURE PREPARATION AND POSITIONING
PRODUCT REFERENCE GUIDE
27
Scanning Station Frame/Mounting Structure Preparation and Posi-
tioning
The vision system components and in particular the mounting brackets have been
designed for installation onto standard Bosch and 80/20 frame profiles (extrusions) and
accessories. 60x60 mm profile is recommended for Bosch, although 45x45 mm profiles
will work; and standard 1.5” x 3” for 80/20.
NOTE: This illustration does not show the current brackets.
