FOCUSING DEVICES
PRODUCT REFERENCE GUIDE
13
Area Sensor
The photoelectric light grids of the AS1 series are crossed-beam area sensors able to
detect all objects, with even 0.2mm thickness, inside a 100mm height, over operating
distances reaching 3m between emitter and receiver. The AS1 area sensors represent
the ideal solution for the detection of very small objects, even when passing in different
positions inside the controlled height and width. Versions with trimmer adjustment and
optic synchronism between emitter and receiver unit are available. Area sensors also
help avoid multiple triggers on irregular shaped packages. See
“Setting up the AS1 Are-
aScan” on page 373.
Area Sensor and Cable (recommended)
AS1-HD-SR-010-J D 3m RES 5mm H 100mm 958101030
CS-A1-03-G-03 M12-5 p 3m (Receiver) 95ACC2110
CS-A1-03-G-05 M12-5 p 5m (Receiver) 95ACC2120
CS-A1-03-G-10 M12-5 p 10m (Receiver) 95ACC2140
CS-A1-02-G-03 M12-4 p 3m (Emitter) 95A251280
CS-A1-02-G-05 M12-4 p 5m (Emitter) 95A251270
CS-A1-02-G-10 M12-4 p 10m (Emitter) 95A251390
