TROUBLESHOOTING
422 AV7000 LINEAR CAMERA
RangeFinder Errors
Info: Reading Illumination
Profile...
Info
The camera is reading the
illumination profile from the
illumination.
The camera reads this data
from the illumination on
power up.
Wait for the camera to finish read-
ing the illumination profile.
Info: Running FSM Self Test Info
RTP is running a test script
to test the focus mechanism
A production test script was
left on the RTP
Contact Datalogic Support
Info: Saving Illumination Pro-
file...
Info
The RTP is in the process of
reading the illumination pro-
file from the illumination.
New illumination was con-
nected to the camera.
Wait until the illumination file is
finished saving.
Info: Sensor Board Loading CCI Info
A Sensor Board software
patch was loaded and is
being written to the sensor.
A Sensor Board software
patch was loaded and is being
written to the sensor.
Wait for software load to complete.
Info: Sensor Board Loading
FPGA
Info
A Sensor Board software
patch was loaded and is
being written to the sensor.
A Sensor Board software
patch was loaded and is being
written to the sensor.
Wait for software load to complete.
Info: Sensor Board Loading
Micro
Info
A Sensor Board software
patch was loaded and is
being written to the sensor.
A Sensor Board software
patch was loaded and is being
written to the sensor.
Wait for software load to complete.
Info: SyncNetwork is not con-
nected in a loop
Info
The AV7000 sync network is
not connected in a loop.
One of the two sync network
Ethernet ports, on one of the
cameras in the tunnel, does
not have a cable connected.
Make sure cables are connected
from the "In" port to the "Out" port
of each camera in the tunnel.
Info: Verifying Sensor Board
Status
Info
The camera is reading the
status information from the
sensor.
Wait for the camera to finish read-
ing the data.
e-Genius Description Type Explanation Possible Cause Solution
e-Genius Description Type Explanation Possible Cause Solution
Error: Image Sensor Read Fail-
ure
Error
The RangeFinder is unable to
read data from the sensor.
Internal RangeFinder error.
Cycle the unit’s power. If the error
persists, replace the RangeFinder
and/or contact Datalogic Support.
Error: Laser #1 current
exceeds limit
Error
The laser current is exceeding
its maximum setting.
Laser is at end of life. Internal
laser failure.
Cycle the unit’s power. If the error
persists, replace the RangeFinder
and/or contact Datalogic Support.
Error: Laser #1 temperature
exceeds limit
Error
The laser is exceeding the
maximum temperature limit.
Ambient temperature is
exceeding the 50 degrees C
maximum operating tem-
perature. Internal laser fail-
ure.
Verify the ambient temperature is
not exceeding 50 C. Cycle the unit’s
power. If the error persists, replace
the RangeFinder and/or contact
Datalogic Support.
Error: Laser #2 current
exceeds limit
Error
The laser current is exceeding
its maximum setting.
Laser is at end of life. Internal
laser failure.
Cycle the unit’s power. If the error
persists, replace the RangeFinder
and/or contact Datalogic Support.
Error: Laser #2 temperature
exceeds limit
Error
The laser is exceeding the
maximum temperature limit.
Ambient temperature is
exceeding the 50 degrees C
maximum operating tem-
perature. Internal laser fail-
ure.
Verify the ambient temperature is
not exceeding 50 C. Cycle the unit’s
power. If the error persists, replace
the RangeFinder and/or contact
Datalogic Support.
Error: No valid temperature
for laser #1
Error
The RangeFinder is unable to
read the laser temperature.
Internal RangeFinder failure.
Cycle the unit’s power. If the error
persists, replace the RangeFinder
and/or contact Datalogic Support.
