MAINTENANCE TASKS
PRODUCT REFERENCE GUIDE
409
1. Switch off the conveyor.
2. Switch off the camera system.
3. Review the exterior cleaning procedure before cleaning the deflection mirror.
4. Check the deflection mirror for any dust, dirt, or smudges. If the deflection mirror
nee
ds to be cleaned, proceed to Step 5.
5. Use a dry, soft, lint-free cloth to remove accumulated dust.
6. If the deflection mirror is particularly dirty or smudg
ed, make a solution of seven
parts denatured alcohol and three parts water. (Many over-the-counter solutions
will leave deposits/smudges that can affect performance.)
7. Apply the cleaning solution to a lint-free cloth.
8. Apply the cloth with the cleaning solution to the mirror.
9. Remove any streaks or remaining moisture from the mirror with a dry, soft, lint-
fr
ee cloth or lens paper.
10. Verify camera operation.
Cleaning the RangeFinder Windows
This procedure is recommended only if it is noticed that the environment is dirty
enough that deposits are appearing on the RangeFinder windows. The cleaning proce-
dure should be performed without removing the RangeFinder from the mounting struc-
ture.
1. Switch off the conveyor.
2. Switch off the camera system.
3. Review the exterior cleaning procedure before cleaning the three windows.
NOTE: Shut down the camera system before performing this maintenance
task. Do not stare into the camera’s window at the LED light. Avoid direct
eye exposure. The LED light level does not constitute a health hazard, how-
ever staring at the LED light for prolonged periods could result in eye dam-
age.
Use care when cleaning the RangeFinder to assure the windows are not
scratched or damaged in any way. Never apply cleaning solution directly to
the windows. Always apply the solution to a cloth, and then the cloth to the
windows.
