ELECTRICAL INSTALLATION
46
AV7000 LINEAR CAMERA
CONNECTING AN AV7000 CAMERA
To install an AV7000, follow this sequence:
1. Complete mechanical installation (See “Mechanical Installation” on page 22.)
2. Complete electrical installation (See wiring diagrams in this chapter.)
3. Observe all electrical safety requirements outlined in this chapter.
4. Ground the mounting structure to protective earth (PE) ground.
5. If used, wire the photoelectric sensor (or
other trigger) and the focusing device
(Light Curtain, S85, DM3610 or RangeFinder) to the CBX connection box.
6. Wire the tachometer to the CBX connection box.
7. Wire serial ports to the CBX connection box if needed.
8. Connect the M12 end of the Ethernet cable to the barcode reader’s Host Net port
and ne
twork switch as required by your application.
9. Wire the Remote Display to the CBX connection box (if used).
10. Connect the AV7000 to its power supply.
11. Connect the power supply to the power source.
12. Setup / check camera operations.
TYPICAL CONNECTION BLOCK DIAGRAMS
NOTE: In each diagram below a Speed Detector may take the place of the
encoder when a tilt-tray or cross-belt conveyance is used.
A CBX510 Connection Box can be used in place of the CBX100 Connection
Boxes shown in the following block diagrams.
