AV7000 TIMING AND DISTANCE DIAGRAMS
PRODUCT REFERENCE GUIDE
135
Focusing with a RangeFinder
Identifier
Item 1
Item 2
Distance
Speed
Standard (in.
)
Metric
m/s
f/m
A
T
rigger Source
RangeFinder
5
127
B
RangeFinder
A
V7000
12
43
2
154
156
