UNPACKING INSTRUCTIONS
PRODUCT REFERENCE GUIDE
23
Tools Required
A 13mm wrench (combination ratcheting wrench recommended) and Philips Screw-
driver (#1) are all the tools needed to assemble and ins
tall the AV7000/AI7000, deflec-
tion mirror, and brackets,
Unpacking Instructions
Verify that the AV7000 Camera and all the parts supplied with the equipment are pres-
ent and intact when opening the packaging; the list of parts includes:
AV7000 Camera
GMC-2034 GR Fan
Hardware Pack:
(2) Knob Knurled, M4 x 6
(4) Mounting Bolts, M8 x 12 UNI 5739 ZB
Test Charts:
CH-3 Autofocus Setting Chart 800x100mm
Dynamic Focus Chart
Picket Fence/Step Ladder Resolution
Installation Guide
AV7000 Downgrade Procedure
The AI7000 comes packaged separately and includes the following:
AI7000 Illuminator
CVL-2389 Cable PS to AI7000, 6M
CAB-503 9P 01M12-IP6 Cable 0.6M
Hardware Pack
(4) M8X1.25,12MM,SEM BOLT,HEX,SS
(4) SCREW M 8 X 8 UNI 5739 ZB
(14) SCREW M 8 X 12 UNI 5739 ZB
(2) SCREW M 4 X 8 UNI 7687 WZ
(4) STUD,T-SLOT,5/16-18X3/4 DROP-IN
(4) LOCKNUT,HEX,5/16-18,SERRATED-FLANGE,STL
(4) SCREW M 8 X 25 HAMMER HEAD+INOX NUT
(2) SPACER H=5 D8 CYL.NICKEL BRASS
Brackets:
(2) - ST-0872 Rising Bracket
(2) - ST-326 Support Bracket
(2) - ST-0871 Main Bracket
NOTE: The AV7000 Camera and accessory packaging is designed to protect
the unit(s) during shipment. Do not throw it away. Save all packing mate-
rial in case you need to transport your unit(s).
Be sure to retain shipping boxes and packing material for use if the unit
needs to be returned to Datalogic for any reason.
NOTE: Be sure to retain shipping boxes and
packing material for use if the
unit needs to be returned to Datalogic for any reason.
