SYSTEM INFO
PRODUCT REFERENCE GUIDE 95
Green = No errors and ready to read
Gray = Unit not connected
Yellow = Warning present, if you click on the MAC address, it will take you to the status viewer
page for more info on the error
Red = Error, if you click on the MAC address, it will take you to the status viewer page for more
info on the error
MAC Address
Displays the internal MAC Address (Media Access Control Address) Since all MAC addresses are
unique, it is the information that the camera uses in the cluster to share data from camera to
camera. Click the MAC Address link to view details about that specific device (See Device
Details below).
IP Address
Displays the internal Sync Net IP address of the unit used for camera-to-camera
communication.
Camera Position
Select Not Assigned, Top, Left, Right, or Bottom from the drop-down list.
Camera Name
Displays the camera's name assigned in Modify Settings | Device Settings | <device> | Device
Info.
Action
Click Blink. This identifies the camera in the array. When clicked, the camera illumination turns
on for around 10 seconds.
Click
Delete. This will remove the camera from the cluster.
External Controller
Displays the status, MAC Address, IP Address and Name of an external controller if the system
requires one.
Cameras not in this Cluster
Displays a list of discovered cameras not currently included in the cluster. This includes the
same information listed above for each camera.
External Devices in this Cluster
Displays a list of external devices currently included in the cluster. These are Datalogic products
that AV7000 and AV500/900 cameras can communicate with, but are not part of the SyncNet
network. This includes the same information listed above for each device.
External Devices not in this cluster
Displays a list of external devices not currently included in the cluster. This includes the same
information listed above for each device.
3. When you have finished making changes, click Update to save or click Reset to
revert to the previously saved values.
Device Details
From the System Info window, click on a device’s MAC Address to open a window dis-
playing details about that device. The details include statistics, decoder, software, and
processor information.
WARNING: Delete should never be selected in an already configured array.
