E-GENIUS
104
AV7000 LINEAR CAMERA
used in bidirectional systems, in which you may want to read codes going forward or reverse.
“Online Mode” on page 116 in Online operating mode, the reading phase is defined as the
time between a Phase ON and Phase OFF event. The Phase events can be signals coming from
one or two external presence sensors connected to the camera inputs or a message start/stop
strings sent from the host over the serial interface or Ethernet input.
“Continuous Mode” on page 120 is continuous image / frame acquisition mode with
immediate decode result processing and transmission. Frames are acquired at the rate
selected. Suppression filters are available for eliminating duplicate decode results within a
single frame and across multiple frames and can be configured either based on time or
distance. When using a distance based suppression filter, distance can be based on a physical
encoder where the clock time to timeout will be dependent on how fast the belt is running or
where time will be based on an internal tach set to 1 meter per second. An option for code
replication is also available where a decode result is replicated or not suppressed when the
same code value is decoded but the code types are different.
Enable Mass Flow Support
Click the check-box to enable Mass Flow Detection System features.
NOTE: Image Saving does not work in Continuous Mode.
