PRODUCT REFERENCE GUIDE
155
•See “Standard Multi-Label” on page 158: In Multi Label mode the barcodes selected
(up to 10), will all be read in the same reading phase. If the reading phase terminates before
all the codes are read, and a No Read message is enabled, Local or Global, a no read message
is produced.
•
See “Logical Combination” on page 161: Logical Combination allows for grouping bar
codes together. You can create an AND or Xor condition. For example: if three codes are
enabled each bar code can be put into separate groups creating an AND condition or you can
place two of the bar codes in one group and a third bar code in a separate group. Group 1
(code 1 or code 2) Group 2 (code 3). You can have either code 1 OR code 2 read and it's data
will be place in Group's 1 field. In Logical Combination mode the codes of the groups defined
by the Logical Combination Rule are read in the same reading phase.
•
See “Code Collection” on page 171: In Code Collection mode expected codes are
collected within a single reading phase in the order in which they are read. The No Read
message is produced only if none of the codes are read. Up to 50 codes can be collected.
Based on your code combination selection, different fields will become available. See
the following sections for the details of your code combination.
3. When you have finished making changes, click
Update to save or click Reset to
revert to the previously saved values.
NOTE: If there are multiple barcodes within the barcode readers read area
during a trigger cycle, the first barcode decoded will be the data transmit-
ted to the host.
NOTE: In case of Standard Multi Label, the codes will be distinguished
EITHER by their symbology, OR by their contents. If two (or more) codes
share the same symbology and content, the barcode reader will perceive
them as a unique code.
