PRODUCT REFERENCE GUIDE
163
No Read Message
Select Disable No Read Message, Global No Read Message, or Local No Read(s) Message from
the drop-down list. The No Read condition occurs whenever a code cannot be read or decoded.
Disable No Read Message: The No Read Message is not transmitted.
Global No Read Message: The No Read String will be sent if the barcode reader is unable to
decode one or more barcodes in the reading phase.
Local No Read(s) Message: This option is useful when one or more codes are not read in
the reading phase or when more codes than the expected number set by the configuration
parameters are read.
No Read String (max. 128 chars)
Click to “Enter Text with the Text Entry Tool” on page 92 and create a string to be
displayed when Global No Read Message is selected from the No Read Message drop-down
list.
Multiple Read Message
Select Disable or Enable from the drop-down list. This string will be sent if, during the
reading phase, the barcode reader reads more than the number of the expected barcodes set
by the configuration parameters.
Multiple Read String (max. 128 chars)
Click to “Enter Text with the Text Entry Tool” on page 92 and create a string to be
displayed in case of Multiple Read Message.
This parameter is only available when Multiple Read Message is enabled and the No Read
Message selection is different from Local No Read(s) String. It is possible to select either the
ASCII or HEX value. If disabled, the barcode reader transmits the first code read.
Send All Multiple Read Labels
Select Enable, Disable from the drop-down list. Available with Standard Multi Read, Logical
Combination and Code Collection. When set to Disable, if there are two or more codes during
the read cycle, the camera will transmit the first decoded bar code and ignore all other bar
codes with matching parameters. When enabled the camera will read all bar codes having the
same symbology and number of characters.
Partial Read Is Treated As
Select No Read, Good Read, or Partial Read from the drop-down list.
A Partial Read is a condition when multiple barcodes are enabled, but not all barcodes are read
during a trigger cycle.
Multi-Filter Settings
Strip Filter
Select the check box to display the Strip Filter Settings options. This filter, when enable, allows
eliminating characters not managed by the host.
Strip All Non Printable Chars
Select the check box to remove all non- printable ASCII characters from the code.
Char(s) to be Stripped
Click to “Enter Text with the Text Entry Tool” on page 92 and enter specific
characters to be stripped from the code.
Strip Filter Collapse
Select the check box to remove the stripped characters from the code and, therefore, reduce
the code length (collapsed). It can even be null.
Replacement Char
Click to “Enter Text with the Text Entry Tool” on page 92 and enter the
substitution character to replace all the stripped ones.
