Datalogic AV7000 User Manual

PRODUCT REFERENCE GUIDE 205
Terminator
Click to “Enter Text with the Text Entry Tool” on page 92 and create a terminator
string. Terminators (up to 128 bytes) can be defined and transmitted as a block following the
barcode(s). Characters from NUL (00H) to ~ (7EH) can be used.
Multiple Label Separator
Click to “Enter Text with the Text Entry Tool” on page 92 and create a separator
string. Separators (up to 128 bytes) can be defined. Characters from NUL (00H) to ~ (7EH) can
be used. This is only available if your configuration is Multi-Label, Logical Combination or Code
Collection.
Multiple Code Item Separator
Click to “Enter Text with the Text Entry Tool” on page 92 and create a separator
string. Separators (up to 128 bytes) can be defined. Characters from NUL (00H) to ~ (7EH) can
be used.
Multiple Global Item Separator
Click to “Enter Text with the Text Entry Tool” on page 92 and create a separator
string. Separators (up to 128 bytes) can be defined. Characters from NUL (00H) to ~ (7EH) can
be used.
Global Scale Type
Select Metric, Imperial, Encoder Units, or Normalized (0-255) from the drop-down list.
•
Metric: Metric length units are used
•
Imperial: Imperial length units are used
Global No Read Type
Click the drop-down to select from Only No Read, Leading, or Trailing.
ADVANCED FORMATTER GLOBAL NO READ TYPE EXAMPLES:
Assume the Global No Read message is defined as NOPE and Two Protocol Index
Messages are being sent to the Camera as additional Fields in the Advanced
formatter.
Example 1 - Single Label
Bar code is not read.
Global No Read Type selected is Only No read.
Host message = Global No Read Defined under barcode configuration
NOPE
Global No Read Type selected is Leading.
Host message = Global No Read_PI1_PI2
NOPE_PI1_HI1!_0004_PI2_Hi2!_0004
Global No Read Type selected is Trailing.
No Read: Host message = _PI1_PI2<Global No Read>
_PI1_HI1!_0006_PI2_Hi2!_0006NOPE
Example 2 - Multiple Label
Two Codes enabled. Barcode Configuration set to Global No Read
Global No Read Type selected is Only No read.
Barcode 1 No read Barcode 2 Read or Barcode 1 Read Barcode 2 No Read or Both codes not
read
Host message = Global No Read Defined under barcode configuration
NOPE
Global No Read Type = Leading
Barcode 1 No read Barcode 2 Read
Host message = Global No Read_PI1_PI2
NOPE_PI1_HI1!_0013_PI2_Hi2!_0013
