PRODUCT REFERENCE GUIDE 269
1. In the menu tree under Modify Settings, navigate to Modify Settings | Device Set-
tings | Camera N | Ethernet | Advanced Routing. The Advanced Routing window
opens.
2. Enter the appropriate information in the form as described below:
Add a Route for Camera_1
Network IP
Enter the Internet Protocol (IP) address of the network in the field provided. Consult your
network administrator to obtain a new address. Available only in static IP mode.
Network Mask
Enter the device network mask address in the field provided. Consult your network
administrator to obtain a new address. Available only in static IP mode (when DHCP is not
selected).
Interface
Select from the drop-down.
Gateway
Enter the device gateway address in the field provided. Consult your network administrator to
obtain a new address. Available only static. IP mode (when DHCP is not selected).
Advanced Route Settings
Displays the linux command created from the entries into the above fields.
3. When you have finished making changes, click Update to save or click Reset to
revert to previously saved fields.
