AV7000 LINEAR CAMERA
2. From the System Status window, the following information is available:
Tunnel/Array Statistics
Conveyor Speed(mm/s)
Belt speed shown in millimeters per second.
Conveyor Speed(fpm)
Belt speed shown in feet per minute.
Encoder frequency Hz
The current encoder frequency computed from the current Belt Speed and the Encoder
Resolution.
Statistic Elapsed Time
Time elapsed from the last reset or the last modification to the configuration of the system.
This is reset at startup and when Reset Counts is clicked.
Total Packages
Package count since last reset.
Good Reads
Number of good packages read since last reset.
No Reads
Number of packages not read since last reset.
Multiple Reads
Number of packages read multiple times since last reset.
Partial Reads
Number of partially read packages since last reset.
Read Rate
Number of packages read out of total number of packages since last reset.
Average Pack Size
The average size of packages since last reset.
Average Pack Distance
The average distance between packages read since last reset.
Total Barcodes
The total number of barcodes read since last reset.
Barcodes Discarded
The total number of barcodes discarded since last reset.
Barcodes In
Total number of barcodes found on the packs detected by the system.
Barcodes Out
Total number of barcodes found outside the packs detected by the system.
Barcodes Uncertain
Total number of barcodes found that intersect more than one pack, and are therefore
ambiguous. A barcode was read but couldn’t be assigned to a package.
Possible reasons:
•Package spacing is too small and the code can be placed on more than one package.
•Verify Package Detection Settings
•Adjust advanced Packtrack settings
•Re-PackTrack camera
NOTE; Statistics have been added to the camera to provide for a future
interface with DL-Stat.
