280
AV7000 LINEAR CAMERA
previous trigger cycles.
Package Information
The following information is displayed:
Trigger: Tachometer information for each phase. The 'Trigger field provides the following
information:
Package Time: Date and time that the camera saw the package
PE Tach Start: Tach count when the PE went active
PE Tach End: Tach count when the PE went inactive
TachStart: the internal tachometer count seen at the start of the trigger
Tach End: The tachometer count at the end of the trigger signal
Length: Length of the package in millimeters and inches
Spacing: the space between the current and previous package. This is posted in millimeters
and inches. When the camera is mounted to read multiple surfaces of the package (ie side and
back) this parameter specifies a condition where one package, because of illegal spacing,
blocks part of the surface of another package. The camera is able to detect this condition and
will post pertinent information.
Volumetric: The Volumetric information is valid when the camera is connected to a DM3610.
The camera will take the data it receives for the package from the DM3610 and fill the
appropriate fields general package size/position
Shadowing: Indicates camera spacing and whether there is shadowing
DM3610 Msg Tracking: When the DM3610 transmit message is set to Camera Message, the
camera will receive the data without the need for any other configuration such as Protocol
Index. When this is set and the message is not received within the correct package tach stamp,
it will post the Msg Missed Window in this field.
Protocol Index: Protocol data if enabled. Identifies when the Protocol Index window opens
and closes and the position of the parcel in tach/encoder pulses.
Transmit Messages: The Transmit Message field will identify the enabled communication
Transport and the message that is transmitted out of that port.
Image Saving: Stored Images are displayed for each camera. Click on the link to access a view
of that camera’s images. Camera N’s Images. see
“Viewing Camera Images” on
page 286, view of the cameras image for the select sequence number.
Decoding Status: Identifies the decoding status of each camera in the array and the
processing load (how hard the processor has to work to decode the bar code). The higher the
number the more processing time it took to identify the bar code data.
Image Analysis: NOT USED, FOR FUTURE RELEASE!
Decode Results: Posts the barcode data and indicates the camera that read the code
End of Sequence Number: Identifies the total number of packages with history stored in
the camera
Camera Statistics
Statistics for each system camera are shown in rows with the following columns:
Camera Name
Displays the camera/device name. Click the device name to view details about that specific
device:
