Emotron VS10 - Page 118

118 01-6203-01R3, CG Drives & Automation
Parameter
Name / value range / [default setting]
Info
0x2917
(P220.00)
Acceleration time 1
(Accelerat.time 1)
0.0 ... [5.0] ... 3600.0 s
Acceleration time 1 for the operating mode "MS: Velocity mode".
• The acceleration time set refers to the acceleration from standstill to the
maximum frequency set. In the case of a lower setpoint selection, the
actual acceleration time is reduced accordingly.
• Setting is not effective in the operating mode 0x6060 (P301.00) =
"CiA: Velocity mode [2]". Device pro file CiA 402
 299
0x2918
(P221.00)
Deceleration time 1
(Decelerat.time 1)
0.0 ... [5.0] ... 3600.0 s
Deceleration time 1 for the operating mode "MS: Velocity mode".
• The deceleration time set refers to the deceleration from the
maximum frequency set to standstill. In the case of a lower actual
frequency, the actual deceleration time is reduced accordingly.
• Setting is not effective in the operating mode 0x6060 (P301.00) =
"CiA: Velocity mode [2]". Device profile CiA 402
 299
0x2919
(P222.00)
Acceleration time 2
(Accelerat.time 2)
0.0 ... [5.0] ... 3600.0 s
Acceleration time 2 for the operating mode "MS: Velocity mode".
• The acceleration time set refers to the acceleration from standstill to the
maximum frequency set. In the case of a lower setpoint selection, the
actual acceleration time is reduced accordingly.
• The acceleration time 2 is active if the frequency setpoint (absolute
value) ≥ auto switching threshold
0x291B (P224.00) or the trigger
assigned to the function "Activate ramp 2" in
0x2631:039 (P400.39) =
TRUE.
• The acceleration time 2 is also used for changing the MOP setpoint
generated by the "motor potentiometer" function.
• Setting is not effective in the operating mode 0x6060 (P301.00) =
"CiA: Velocity mode [2]". Device pro file CiA 402
 299
0x291A
(P223.00)
Deceleration time 2
(Decelerat.time 2)
0.0 ... [5.0] ... 3600.0 s
Deceleration time 2 for the operating mode "MS: Velocity mode".
• The deceleration time set refers to the deceleration from the
maximum frequency set to standstill. In the case of a lower actual
frequency, the actual deceleration time is reduced accordingly.
• The deceleration time 2 is active if the frequency setpoint (absolute
value) ≥ auto change-over threshold
0x291B (P224.00) or the trigger
assigned to the function "Activate ramp 2" in
0x2631:039 (P400.39) =
TRUE.
• The deceleration time 2 is also used for changing the MOP setpoint
generated by the "motor potentiometer" function.
• Setting is not effective in the operating mode 0x6060 (P301.00) =
"CiA: Velocity mode [2]". Device pro file CiA 402
 299
0x291B
(P224.00)
Auto-changeover threshold of ramp 2 (Ramp 2
thresh.)
0.0 ... [0.0] ... 599.0 Hz
Threshold for the automatic change-over to acceleration time 2 and
deceleration time 2.
• The change-over is effected if the frequency setpoint (absolute value)
≥ auto change
-over threshold.
• With the setting 0, the automatic change-over function is deactivated.
Example for operating mode
Parameter
Name
Setting for this example
0x2631:001 (P400.01)
Enable inverter
Constant TRUE [1]
0x2631:002 (P400.02) Run Digital input 1 [11]
0x2915 (P210.00)
Minimum frequency
15 Hz
0x2916 (P211.00)
Maximum frequency
40 Hz
0x2917 (P220.00)
Acceleration time 1
4 s
0x2918 (P221.00)
Deceleration time 1
3 s
