Cordex®CXCHPControllerSoftwareManual|19-Maintainingthesystem
Notice: If the LVD were to disconnect, the calculated SOC value displays as “- - -”. The
LVD only reconnects once the SOC value is properly calculated again, which happens
once the battery is reconnected and fully charged.
• Uptothreeuserdefinabledisconnectandreconnectconditions.
Notice: The connect voltage should be higher than the disconnect voltage by at least 1 V for a 48
V system and 0.5 V for a 24 V system.
Eachdisconnectcanhavethreedigitalinputsdefinedtoclosethelooponthestatusofthecontactor.
• Disconnect Open Source: Indicateswhetherthedisconnectisopenorclosed.
•
Manual Closed Source: Disconnectissettostayclosed.
•
Manual Open Source: Disconnectissettostayopen.
ToviewtheDisconnects menu,gotoSystems > DC System > Inventory > Disconnects.
Page 178 0350058-J0 Rev AL
