TX150 S8 / TX200 S7
Upgrade and Maintenance Manual 333
Front panel and external connectors
Figure 251: Removing the front panel cable
Ê Remove the front panel cable from the defective front panel module as
shown.
Ê If the front LAN connector has been installed in the defective front panel
module, remove the cable as described in section "Removing the front LAN
connector" on page 344.
