HAIMA 7 - Page 586

47
Mark on harness:
Middle harness (D)
-
Instrument harness (I)
Ignition switch
Right brake lamp
Left brake lamp
Front harness (F) - Instrument harness (I)
EM harness (EM) - Instrument harness (I)
Brake switch
Fuse block (see section
Junction box (see section JB)
Liftgate 2# harness (R2#) -
Middle harness (D)
High mount brake
lamp
Front harness (F) -
Middle harness (D)
