Fuse block (refer to FB
sections)
Junction box (refer to JB sections)
Ignition switch
Front harness (F)-Instrument harness (I)
Middle harness (D)-Instrument harness
Front harness (F)-Middle harness (D)
EM harness (EM)-Front harness (F)
ABS control unit
ABS wheel speed
sensor (left, front)
ABS wheel speed sensor (left, rear)
ABS wheel speed sensor (right, front)
ABS wheel speed sensor (right, rear)
To Next Page
