6-50 Designjet Z Series — Service Manual
Removal and Installation
7. Remove the Front Panel.
When you reinstall the Front Panel,
you must make sure that the Ferrite
Core is correctly positioned. The
Ferrite Core is necessary to avoid
electrostatic interference being
generated.
When you finish installing or replacing this component, you must perform the
necessary Service Calibrations. To find which calibrations you must perform,
Refer to page 6-8,
Service Calibration Guide to Removal and Installation
.
