Designjet Z Series — Service Manual 6-63
Removal and Installation - Service Station
11 . Unclip the clip to release the Service
Station from the printer.
12. Lower the Service Station from the printer.
13. Lower the right of the Service Station
enough to allow you to slide it carefully out
of the printer.
When you finish installing or replacing this component, you must perform the
necessary Service Calibrations. To find which calibrations you must perform,
Refer to page 6-8,
Service Calibration Guide to Removal and Installation
.
