214323 90 Revision A
Reposition the center arm cylinder as follows:
NOTE:
Reel components not shown in illustration for improved clarity.
Figure 3.100: Forward Position – Center Arm
Figure 3.101: Aft Position – Center Arm
6. Remove cotter pin (A) and clevis pin (B).
7. Push the reel back until cylinder barrel (C) lines up with
the aft holes in bracket (D).
8. Reinstall clevis pin (B) at the new position and secure
with cotter pin (A).
OPERATION
