3.8.1 Sensor Output Voltage Range – Combine Requirements
The auto header height control (AHHC) sensor output must be within a specific voltage range for each combine, or
the AHHC feature will not work properly.
Table 3.13 Sensor Voltage Limits
Combine
Low Voltage Limit High Voltage Limit
Minimum Voltage
Range
Challenger, Gleaner A, Gleaner S,
Massey Ferguson
0.7 V 4.3 V 2.5 V
Case IH 5088/6088/7088, 5130/6130/
7130, 7010/8010, 7120/8120/9120, and
7230/8230/9230
0.7 V 4.3 V 2.5 V
Case IH 2300/2500
3.0 V 7.0 V 4.0 V
Gleaner R and S Series
0.7 V 4.3 V 2.5 V
John Deere 50, 60, 70, S, and T Series
0.7 V 4.3 V 2.5 V
CLAAS 500/600/700 Series
0.7 V 4.3 V 2.5 V
New Holland CR/CX - 5 V system
0.7 V 4.3 V 2.5 V
New Holland CR/CX - 10 V system
3.0 V 7.0 V 4.1–4.4 V
NOTE:
Some combine models do not support checking sensor output voltage from cab (early 23/2588 series, CLAAS
500/700 series). For these models, check output voltage manually. Refer to Manually Checking Voltage Range,
page 104.
