MacDon FD75 - Rice Divider Rods

214323 101 Revision A
1010234
A
B
Figure 3.122: Divider Rod on Crop Divider
2. Position crop divider rod (B) on tip of crop divider as
shown and tighten bolt (A).
3. Repeat procedure at opposite end of header.
Rice Divider Rods
1001582
Figure 3.123: Divider Rod for Rice
Optional rice divider rods provide improved performance in
tall and tangled rice crops. Refer to 6.5.6 Rice Divider Rods,
page 488.
The installation and removal procedures are the same as
for standard crop divider rods.
