214323 484 Revision A
6.4 Header
6.4.1 Divider Latch Kit
Figure 6.10: Divider Latch
Divider latch kits attach to the endsheets. They allow for
quick removal and storage of endsheet divider cones and, if
required, reduce the transport width of the header.
Installation instructions are included in the kit.
MD #B5607
6.4.2 Stabilizer Wheels
Figure 6.11: Stabilizer Wheel
Stabilizer wheels help to stabilize the header in field
conditions that would otherwise cause the header to
bounce, resulting in uneven cutting heights. Installation and
adjustment instructions are included in the kit.
MD #C1986
Second Stabilizer Wheel kit
The Second Stabilizer Wheel kit is available to upgrade the
header to two stabilizer wheels. Each kit consists of one
wheel assembly; two kits are required to upgrade both sides
of the header.
Installation instructions are included with the kit.
MD #B6179
OPTIONS AND ATTACHMENTS
