214323 481 Revision A
6.2.4 Reel Endshield Kit
Figure 6.4: Reel Endshields
The steel shields provided in the Reel Endshield kit attach
to the ends of the reels and help to clear material in heavy,
hard-to-cut crops. They are standard equipment on all
headers (except nine-bat reels). Hardware and installation
instructions are included in the kit.
See your MacDon Dealer for more information.
6.2.5 Tine Tube Reinforcing Kit
Figure 6.5: Five-Bat Reinforcing Kit Shown –
Six-Bat Reinforcing Kit Similar
Tine tube reinforcing kits are available for five- and six-bat
reels. They are designed to support high reel loads when
cutting extremely heavy crops.
Installation instructions are included in the kit.
• Five-Bat Reels – MD #B5825
• Six-Bat Reels – MD #B5826
OPTIONS AND ATTACHMENTS
