214323 485 Revision A
6.4.3 Stabilizer/Slow Speed Transport Wheels
Figure 6.12: Stabilizer/Transport Wheels
Stabilizer/slow speed transport wheels help to stabilize the
header in field conditions that would otherwise cause the
header to bounce, resulting in uneven cutting heights. This
system is similar to the Stabilizer Wheel option. Refer to
6.4.2 Stabilizer Wheels, page 484.
Stabilizer/slow speed transport wheels are used to convert
the header into transport mode for slow-speed towing
behind a properly configured combine (or agricultural
tractor). A tow pole and installation instructions are included
in the kit.
MD #C1997
OPTIONS AND ATTACHMENTS
