214323 231 Revision A
NOTE:
It is not necessary to press rocker switch (D) again after
adjusting.
Figure 3.404: Float Indicator Box
NOTE:
The ideal ground pressure—in most cases—is one
number (on float indicator box) above header
suspended off ground. For example, if float indicator
needle (A) is positioned at 0 with header suspended off
ground, then ideal ground pressure will be achieved
with needle positioned at 1. Operating with heavier
pressures can wear cutterbar wearplate prematurely.
Configuring Reel Fore-Aft, Header Tilt, and Header Type (New Holland CR Series)
This procedure applies only to 2016 New Holland CR models 6.90, 7.90, 8.90, and 9.90.
NOTE:
Changes may have been made to the combine controls or display since this document was published. Refer to the
combine operator’s manual for updates.
Figure 3.405: New Holland Combine Controls
1. Simultaneously press both UNLOAD (A) and
RESUME (B) buttons on hydro handle.
OPERATION
