5.15 Transport System (Optional)
Refer to 6.4.3 Stabilizer/Slow Speed Transport Wheels, page 485 for more information.
5.15.1 Checking Wheel Bolt Torque
If a transport system is installed, adhere to the following procedure for torquing the wheel bolts:
1001277
2
3
4
5
6
1
Figure 5.313: Bolt Tightening Sequence
1. Follow the bolt tightening sequence shown, and torque
the wheel bolts to 110–120 Nm (80–90 lbf∙ft).
IMPORTANT:
Whenever a wheel is removed and reinstalled, check
the wheel bolt torque after one hour of operation and
every 100 hours thereafter.
